SELENOID DOSING PUMP TECRA AXL

The innovative Tecra series electromagnetic metering pump with digital drive is a result of NW's 25 years or working closely with our world-wide customers. These multifunctional metering pumps maintain the high reliability that is synonymous with Waterlink quality.
All Tecra series have IP 65 rated enclosure made of Polypropilene reinforced with glass fiber. Thos allow the pumps to be water and impact resistant and corrosion free.



Versatile installation as Tecra series pumps allow for 3 fixing possibilities;
• wall mounting with only one fixing point;
• wall mounting with 2 or 4 fixing points;
• base mounting (on tank or existing wall mounting bracket with optional bracket)



DUAL FLOW RANGE SCALE

Tekra AXL dosing pump es made with a dual flow rate range scale.
By a simple switch is possible to reduce of 1/10 the maximun dosing pump pulse frequency.

Flow rate in l/h at:

l/h
400 imp/min
200 imp/min
100 imp/min
50 imp/min
25
12,5
6,25
3,13
11
5,5
2,75
1,37
5,3
2,65
1,32
0,67
2
1
0,5
0,25



RELIABILITY

All NW pumps are tested using modern technologies; their reliability is assured through use of high quality materials, intensive laboratory tests and life stress tests. Every pumps, is operated 6 hours at maximun speed before the final test.
Test Certificate with pressure/flow rate diagram made under customer specification is available as an option.



CONTINOUS OPERATION

The pumps require only the electrical power supply to work. Flow rate is adjustable through the knob on the front of the pump by changing the number of strokes per minute from 0 to 400.

 SS

LIQUID CONTACTED MATERIALS

Head type
Standard
SP
Pump Head
PP
Connectors
PP
Valve balls
Pyrex
Seals
FPM or EFDM
Diaphragm
PTFE



TECHNICAL DATA

Model

Back Pressure

Flow rate

cc/stroke

Connections
(mm)

Stroke/min

Weight

Bar

L/h

In/Out

Kg
600
20
2
0,08
4/7
400
1,7
601
12
2,5
0,10
4/6
400
1,7
10
3
0,13
6
3,5
0,15
602
8
5
0,21
4/6
400
3,1
5
6
0,25
1
8
0,33
901
16
6
0,25
4/6
400
3,1
14
7
0,29
12
8
0,33
902
10
10
0,42
4/6
400
3,1
6
12
0,50
2
14
0,58
903
5
20
0,83
8/12
400
3,2
3
28
1,17
1
45
1,88
904
2
45
1,88
8/12
400
3,2
1
60
2,50
0
70
2,92

Data obtained with water at ambient temperature and suction height 1.5 metres.
For outdoor installation with direct sun exposure use black delivery tube.



CHARACTERISTICS
Power supply: 230V 50-60Hz -10% + 15%
Isolation class: F
Protection degree: IP65
Working temperature: -10...40 ºC
Pump is supplied with 1,5 metre power supply cable and european plug.
a

CODE ORDERING SYSTEM

Pump Type

Function

Model

Power Supply

Head Type
NA XL 602 A SP
NA= Analogic
TECRA series		 XL= continous with level control input See technical data table A= 230 Vac 50-60Hz
B= 24 Vac 50-60Hz
C= 115 Vac 50-60 Hz		 See technical data table
